Features
- 200 M bandwidths
- 1 GSa/s Real Time sample rate
- Record length up to 24 K
- USB host and device connectivity, standard
- Multiple automatic measurements
- Four math functions, including FFTs standard
- Provides software for PC real-time analysis
Technical Specification
| Bandwidth | 200 MHz |
| Channel | 2 |
| Real-Time Sample | 1 GSa/s |
| Equivalent Sample | 25 GSa/s |
| Memory Depth | 40 K |
| Rise Time | 1.7 ns |
| VOLTS or DIV Range | 2 mV/div to 5 V/div |
| A or D Converter | 8 bits |
| Display | 7 in (17.78 cm) TFT |
| Record Length | Up to 24 k |
| Display Resolution | 800 pixels x 480 pixels |
| Dimensions | 12.32 in x 5.59 in x 4.25 in (313 mm x 142 mm x 108 mm) |
| Weight | 4.58 lb (2.08 kg) |
