Technical Specification
| Max. Sample Rate of Analog Channel | 8 GSa/s (single channel), 4 GSa/s (half-channel), 2 GSa/s (all channels) |
| Max. Memory Depth (Analog Channel) | 200 Mpts (single channel), 100 Mpts (half-channel), 50 Mpts (all channels) |
| Max. Memory Depth (Digital Channel) | 25 Mpts (all channels) |
| Max. Waveform Capture Rate | ≥500,000 wfms/s |
| Hardware Real-time Waveform Recording and Playing | ≥450,000 wfms/s (single channel) |
| Peak Detection | 500 ps glitches |
| Display Size and Type | 9 in (228.6 mm) capacitive multi-touch screen/gesture enabled operation |
| Display Resolution | 1024 × 600 pixels |
| Type | Virtual Oscilloscope |
| Customized Support | OEM |
| Analog Bandwidth | 70 MHZ to 200 MHZ |
| Channels | 2 Channels to 4 Channels |
