Overview
Hospitality Enviro Tech underground cable fault locator is used for power cable main insulation fault location (prepositioning). Support TDR, ICM, MIM, solve low resistance, high resistance, flashover fault location.
Features
- Multi range positioning method:
- Small current impulse method is suitable for small resistance fault location
- 400 MHz real time sampling
- Touch screen and key operation
- Large screen colour LED, friendly interface
- 7-inch LED display, 160 ° viewing angle, 750 cd / m2 bright in the sun
- Waveform storage and PC communication
- Built in polymer lithium-ion battery, working time can reach 7 hours each time
- Special software management is used for software upgrade
- Power management
Technical Specifications
| Measuring range | 0.12 mi to 62.13 mi (200 m to 100 km), 65.61 ft to 62.13 mi (20 m to 100 km) can be selected |
| Resolving power | 7.874 in (0.2 m) |
| Sampling rate | 400 Mhz |
| Display | 7-inch LED display |
| Interface | USB |
| Output impedance | 33 Ω |
| Power supply | 220 V or 50 HZ |
