Overview
Hospitality Enviro Tech underground cable and pipe locator system underground cable fault detector can accurately locate and measure the buried depth of underground pipelines, cables, and optical cables without excavation, and accurately find the location of the damaged point of the outer anti-corrosion layer of the underground pipeline and the fault point of the buried cable. and is suitable for various underground the detection and inspection of metal pipelines, pipeline management and maintenance, municipal planning and construction, power supply and other departments are the necessary instruments for pipeline maintenance units.
Features
- Multiple Functions
- Three connection modes for the transmitter: inductive, direct, and clamp
- Receiver detects position, path, depth, and tube current of underground pipes and cables
- Provides precise pipeline, arrows, damage indication, backlight for night use
- Optional GPS geo location and professional data analysis software
- Unique feature (HZ-4000) for locating breakdown points, damages
- High Location Accuracy
- Various measurement modes for pipeline positioning ensure accuracy
- Maximum and minimum value methods for horizontal and vertical components
- Measuring Depth
- Multiple methods for depth measurement verification
- Strong Anti-interference Ability
- Measures horizontal component, vertical component, and horizontal gradient
- Adjustable transmitter output power and multiple working frequencies for flexibility
- Easy Operation
- Intuitive graphical display for real-time parameter visualization
- Automatic depth measurement with two-level antenna mode
- Long Continuous Working Time with Low Cost
- Large capacity lithium battery packs for both transmitter and receiver
- Full recharge lasts a whole working day outdoors, reducing detection costs
- AC and DC
- Built-in battery pack for normal use, with the option to use a power
- Adapter if battery power is low
Technical Specifications
| Depth Accuracy | line ±2.5% 0.1 m to 0.3 m |
| Battery | 2 x D-cell LR 20 |
| Usage | 30 h |
| Depth Range | 5 m |
| Dynamic Range | 140 dB rms or Hz |
| Selectivity | 120 dB or Hz |
| Warranty | 1 years |
| Weight | 3.96 lb (1.8 kg) |
