Overview
Hospitality Enviro Tech ultrasonic thickness gauge meter used for measuring thickness and corrosion of pressure vessels, chemical equipment, boilers, oil storage tanks, industries of petroleum, shipbuilding, power station and machine manufacturing.
Features
- High resolution measurement
- Probe automatic zero calibration for system error correction
- Capture the value of the minimum thickness
- Status indicator of the coupling and low battery
- Auto sleep and auto power off function to conserve battery life
- Humanized shape design, compact and portable
- Can be used in harsh environment
Technical Specification
| Display | 4.5 digits LCD with EL backlight |
| Operating principle | ULTROSONIC |
| Measuring range (metric/Imperial | 0.03 in to 7.87 in (1.0 mm to 200 mm),0.05 in to 8 in (in Steel) |
| Resolution | 0.00 in (0.1 mm) |
| Accuracy | ± (0.5% H) + 0.00 in (0.1 mm), depending on materials and conditions |
| Units | Metric/Imperial unit selectable |
| Power supply | 4 x 1.5 AAA size battery |
| Battery indicator | low battery indicator |
| Operating conditions | 32 °F to 113 °F (0 °C to + 45 °C), 32 °F to 104 °F (0 °C to 7.22 °C), ≤90% RH |
| Dimensions | Main Unit: 0.03 in x 2.36 in x 0.86 in (140 mm × 60 mm × 22 mm) |
| Standard delivery | Main Unit, 0.31 in (8 mm) Probe, Coupling Oil, User Manual, Carrying Case |
