| Detection range |
0 in to 236.2 in (0 mm to 6000 mm) |
| Gate alarm |
Alarm buzzer and LED alarm |
| Sound speed range |
1000 m/s to 15000 m/s |
| Widening inside the door |
Enlarging echo details for easy analysis of echoes |
| Detection range |
0 in to 236.2 in (0 mm to 6000 mm) |
| Gate alarm |
Alarm buzzer and LED alarm |
| Sound speed range |
1000 m/s to 15000 m/s |
| Widening inside the door |
Enlarging echo details for easy analysis of echoes |
| Detection range |
0 in to 236.2 in (0 mm to 6000 mm) |
| Dynamic range |
≥36 dB |
| Operating frequency |
0.5 MHz to 10 MHz |
| Waveform Freeze |
Freezes the waveform displayed on the screen for defect analysis |
| Vertical linearity error |
≤3.0% |
| Surface correction |
Display circumferential position and depth in real time |
| Horizontal linearity error |
≤0.2% |
| Sensitivity margin |
>60 dB |
| Pulse amplitude |
200 V, 300 V, 400 V, 500 V, 600 V grading selection |
| Crack sounding |
Automatic measurement, Calculation of crack height |
| Pulse width |
Continuously adjustable within (30 ns to 510 ns |
| Weld illustration |
Visual display of weld map and defect location |
| Band range |
0.5 Mhz to 10 MHz |
| Working time |
>10 hrs |
| Screen resolution |
320 pixels x 240 pixels |
| Storage function |
16 GB memory card |
| Dimensions |
11.0 in x 8.6 in x 2.7 in (280 mm x 220 mm × 70 m) |
| Continuous record |
2 hrs |
| Number of channels |
1000 |
| Probe damping |
68 Ω, 100 Ω, 150 Ω, 500 Ω |
| Echo coding |
1 to 6 echo display areas |
| Battery module |
High capacity lithium battery, Online charging |
