Features
- Automated display precise flaw location Depth level distance and amplitude
- Automated calibration of transducer Zero point, Angles, Front edge
- Convenient to make and use DACTCG and AVG to evaluate the echo
- Automated make video of test process and play: the length of video
- Powerful pc software and reports can be exported to excel
Technical Specifications
| Vertical Linearity Error | ≤3% |
| Horizontal Linearity Error | ≤0.1% |
| Sensitivity Leavings | ≥dB 62 |
| Dynamic Range | ≥dB 32 |
| Resolving Power | ≥dB 36 |
| Frequency Range | 0.5 MHz to 15 MHz |
| Gain | 0 dB to 120 dB |
| Material Velocity | 1000 m/s to 15000 m/s |
| Measurement Mode | Single, Dual, Thru |
| Reject | 0 % to 80 % |
| Pulse Displacement | -20μs to + 3400 μs |
| Zero | 0.0 μs to 99.99 μs |
| Operating Temperature | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Measuring Range | 0 in to 393.70 in (0 mm to 10000 mm) |
| Size | 9.44882 in × 6.14 in × 1.88 in (240 mm × 156 mm × 48 mm) |
| Weight | 2.20 Ib (1.0 kg) (with battery) |
