Features
- Automated calibration of transducer Zero Offset or Velocity
- Automated gain, Peak Hold & Peak Memory
- Automated display precise flaw location
- Automated switch
- 100 independence setup
- Big memory of 300 A graph
- Gate and DAC alarm
- Acoustic-Optical alarm
- Easy to connect with PC
- Embedded software can be online updated
- Li battery, continue working time up to 10 hrs
- Display freeze
- Automated echo degree
- Angles and K value
- Lock and unlock function of system parameters
- Electronic clock calendar
- Two gates setting and alarm indication
- High-speed capture and very low noise
- Solid metal housing
Technical Specifications
| Measuring range | 0 in to 236.2 in (0 mm to 6000 mm) |
| Gain | (0 dB to 100 dB) |
| D-Delay | -20 µs to +3400 µs |
| Resolution | 0.003 in (0.1 mm) 0.09 in to 3.93 in (2.5 mm to 100 mm) 0.03 in (1 mm) >3.93 in (>100 mm) |
| P-Delay | 0 µs to 99.99 µs |
| Material Velocity | 1000 m/s to 9999 m/s |
| Temperature | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Humidity | 20% RH to 90% RH |
| Power | 7.4 V 4800 mAh |
| Working time | >8 hrs |
| Display | LED true color |
| Size | 9.3 in x 6.2 in x 1.9 in (238 mm x 160 mm x 50 mm) |
| Weight | 2.2 lb (1 kg) |
