Features
- strength measurement
- deficiency measurement
- depth measurement
- width measurement
- Automatic interpretation of first wave time and amplitude
- no manual interpretation
- direct display of detection results
Technical Specifications
| Display mode | 10.1 “color LCD screen |
| Trigger mode | Automatically triggered |
| Sampling interval | 0.025 μs to 2000 μs |
| Sampling length | 512 to 2048 points multi-file optional |
| Receiving sensitivity | ≤ 10 μV |
| Measurement range of sound time | 0 μs to 4000000 μs |
| Amplitude reading range | 0 dB to 170 dB |
| Transmission voltage | 125 V, 250 V, 500 V, 1000 V multiple options |
| Pulse width of emission | 0.1 μs to 100 μs |
| Storage capacity | 16 GB |
| Transfer mode | special U disk |
| Charging power supply | AC 100 V to 240 V, 50 Hz / 60 Hz, output 12.6 V DC, 3.0 A |
| Host volume | 11.141 in × 8.5 in × 1.61 in (283 mm × 216 mm × 41 mm) |
| Host weight | 3.96 lb (1.8 kg) |
| Operating temperature | -4 °F to 140 °F (-20 ℃ to +60 ℃) |
| Depth measurement range | 0.19 in to 19.68 in (5 mm to 500 mm) |
| Width measurement range | 0.0004 in to 0.4 in (0.01 mm to 10 mm) |
