Technical Specifications
| Measuring range | 0 NTU to 1000 NTU, 0 NTU to 100 NTU ,0 NTU to 20 NTU |
| Measuring principle | Scattering light method |
|
Accuracy |
±5% or ±3 NTU(0 NTU to 1000 NTU)
±3% or ±2 NTU(0 NTU to 100 NTU) ±3% or±1.5 NTU(0 NTU to 20 NTU) ±0.5℃ |
| Calibration mode | Two-point calibration |
| Temperature compensation | Automatic temperature compensation(Pt1000) |
| Output mode | RS-485( Modbus /RTU) |
| Working conditions | 0 ℃ to 50 ℃，<0.2 MPa |
| Storage temperature | -5 ℃ to 65 ℃ |
| Installation mode | Immersive installation, 3/4NPT thread |
| Cable length | 5 meters, other lengths customizable |
| Power dissipation | ＜0.3 W@12 V |
| Source | 12 V to 24 V DC ±10% |
| Protection grade | IP68 |
