Technical Specifications
| Output signal | RS485, MODBUS/RTU |
| Measurement method | 90 ℃ scattered light method |
| Range | 0 to 1000 NTU |
| Resolution | 0.1 NTU, 0.℃ |
| Operating conditions | (0 ℃ to 50 ℃), <0.6MPA |
| Calibration method | Two-point calibration |
| Response time | 30 seconds T90 |
| Temperature compensation | Automatic temperature compensation (PT1000) |
| Power supply | 12 or 24 V DC ±10%, 10 MA |
| Size | 30MM diameter, 166.5 mm length |
| Protection class | IP68; Water depth 20 m |
| Cable length | 5 m (default), customizable |
| Sensor housing material | PVC or titanium alloy (other) |
