Features
- Compact and portable
- Diversified wireless communication
- Powerful bar code scanning function optional
- RFID frequency optional
Technical Specifications
| Product Type | portable wholesale touch screen GPS 865 MHz to 868 MHz
UHF handheld android barcode scanner RFID reader writer |
| Display | 5 in (127 mm) IPS HD screen, resolution 720×1280 |
| Touch Screen | Industrial multi-touch capacitive screen |
| Expansion slot | 1SIM, 2PSAM
1MicroSD (TF) |
| Communication Interface | USB2.0, 3.5 plug charging interface |
| Audio | Voice broadcast |
| Indicator light | Network indicator, charging indicator |
| Key | Scan key, function key |
| Camera (optional) | 8-megapixel rear camera with flash and autofocus function |
| Flashlight | Low-power LED lighting, used in emergency |
| GPS(Optional) | Built-in GPS global positioning system, range error ± 5m |
| CPU | Quad-core 64-bit Cortex-A53 |
| Memory | RAM: 2GB, ROM: 16GB |
| Operating System | Android 5.1.1 |
| Expansion | Supports up to 32GMicro SD card |
| 4G | TDD-LTE Band 38/39/40
FDD-LTE Band 1, 2, 3, 4, 7 |
| 3G | WCDMA (850 MHz / 1900 MHz / 2100 MHz) |
| WIFI (Optional) | 2.4G/5G, comply with IEEE 802.11a / b / g / n |
| Bluetooth | Bluetooth 4.0 |
| Operating temp | -4 ℉ to 122 ℉ (-20 to 50℃) |
| Storage temp | -4 ℉ to 158 ℉ (-20 oC to 70 ℃) |
| Degree of Protection | IP 65 |
| Battery capacity | Li-polymer, 4500 mAh |
| Stand-by time | 360 hours when turning off the wireless communication and other functions |
| Operating hours | 12 hrs or more (full charge) |
| Charging time | <4.5 hrs |
| 1D Barcode | Undecided and decoded Scan mode: single-line Interface: Undecoded:10-pin ZIF connector, Decoded:12-pin ZIP connector RS-232(TTL) Scanning angle: 47±3° (default) /35±3° (BWR) Scan rate: 104 scans / s ± 12 scans / s |
| Barcode | 2D Barcode: PDF417, QR Code (Model 1/2), Data Matrix (ECC200.ECC000,050080.100.140), Aztec, Maxiccde etc1D Barcode: Code128.EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codaba, China Post 25, interleaved 2 of 5, ISBN/ISSN. Code93etc |
| UHF | ETSI:865 MHz to 868 MHz OR FCC:902 MHz to 928 MHz Working protocol: ISO18000-6C Reading distance: 0 mm to 7000 mm (Ranges depend on tags and environment)Anti-collision (optional): 200 pcs/s Output power: 0 dBm to 30 dBm/2 W |
| HF | Working frequency: 13.56 MHz Working protocol: ISO14443A&ISO15693 Reading distance: 0 mm to 70 mm (Ranges depend on tags and environment) |
| LF | 125 kHz/134.2 kHz |
| PSAM | 2PSAM |
| HF (CPU CARD) | Read & write, work only with PSAM |
| Active 2.45G (Custom) | Reading distance: 7874.01 in (200000 mm), 200pcs/time reading |
| 433M (Custom) | Reading distance>7874.01 in (200000 mm), reading distance could be customized |
| ZIGBEE (Custom) | Applicable wireless network data acquisition |
| Sensor | TCS1 Biological fingerprints /FBI certificated |
| Function | Enrolment, compare, and deletion |
| Sensor Type | Inductive capacitance |
| Image Size | 256 x 360 pixel |
| Resolution | 500 DPI |
| Storage Memory | 1000 fingerprints |
| Standard | Li-poly battery, charging head, DC cable, USB cable |
| Optional | Recharging cradle |
| Document | Demo, API, software development guidance |
| Size | 6.69 in × 3.35 in × 0.91 in (170 mm × 85 mm × 23 mm) |
| Weight | 0.83 lb (380 g) |
