Features
- IR temperature measurement with resolution 32 x 31 pixels
- Hot Spot and Cold Spot Tracking
- Visual Camera & Images Capture (BMP)
- MicroSD memory card
- Date/time setup controls, Adjustable emissivity & trigger lock
- Li-ion rechargeable battery
- SB interface to smartphone / PC
- Language selection: English, Chinese
- Meter box IRTP & cloud service
Technical Specifications
| Thermal sensitivity (NETD) | 0.27 (0.15 ℃) 1 Hz and 100 ℃ |
| Image frequency | 9 Hz |
| Detector type | Uncooled hyper-thin pyroelectric ceramic |
| Spectral range | 6.5 μm to 14 μm |
| IR resolution | 32 pixels x 31 pixels |
| Display | 2.2″ TFT 320 x 240 pixels colour LCD display |
| Object temperature range | -4 ℉ to +572 ℉ (-20 ℃ to +300 ℃) |
| Accuracy | ±2% 35 °F (±2 ℃) as tested |
| Spot | Hot spot and cold spot tracking |
| Emissivity adjustable | 0.10 to 1.0 adjustable |
| Micro SD memory card | MAX. support 8GB |
| Field of view | 38° x 38° |
| Colour palettes | Hot metal / iron bow / rainbow / rainbow high contrast / grayscale |
| Image storage format | Standard BMP, including measurement data, on memory card > 1000 pictures |
| Product Size | 4.92 in x 2.28 in x 8.07 in (125 mm x 58 mm x 205 mm) |
| Weight | 1.09 lb (494 g) |
