Features
- 11 adjustable record intervals
- Versatile communication options
- Full support for 32 signals
- 16 total isolations
- High-quality automatic SMT patch process enhances production efficiency
- Fully isolated design reduces signal interference
- Safe, stable, and durable ABS flame-retardant material
Technical Specifications
| Accuracy | Real time display +-0.2% F.S Recall accuracy +- 0.2% F. S |
| Processor | High – performance arm Cortex- M3 32-bit RISC core can be used to collect, record, display and alarm multiple signal |
| Voltage input | 0 V to 5 V, 1 V to 5 V or 0 mV to 20 mV or 0 mA to 100 mA |
| Current input | 0 mA to 10 mA, 4 mA to 20 mA, 0 mA to 20 mA |
| Resistor input | 0 Ω to 400 Ω |
| Thermal resistance | PT 100, Cu 50, G53, Cu100, BA1, BA2 |
| Alarm output | Up to 6 relay alarm output |
| Recording capacity | 248 MB |
| Power supply | 100 VACS to 240 VAC, 50 HZ or 60 Hz Ac power supply |
| Storage temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Working temperature | 32 °F to 122 °F (0 ° C to 50 ° C) |
| Weight | <= 3.30 lb (1.5 kg) |
