Features
- Flexible adjustment of 12 record interval multiple communication options
- Multiple signals are supported 6 channel total isolation
- Automatic SMT patch process at the basic of high quality
- Improve the production efficiency
- Fully isolated design effectively reduces signal interference between circuits
- And can increase channel numbers
- ABS flame retardant material safe stable and durable
Technical Specifications
| Data memory | 128 Mb, 900,000 records |
| Power supply | AC 100 V AC to 240 V AC 50 Hz or DC 24 V DC, 10 % |
| Measurement Accuracy | 0.2% F.S |
| Current | 4 mA to 20 mA, 0mA to 20 mA, 0mA to 10 mA |
| Voltage | 1 V to 5 V, 0 V to 5 V, 0 V to 10 V 0 mV to 100 mV, 0 mV to 20 mV |
| Temperature | Temperature 14 °F to 140 °F (- 10 ℃ to 60 ℃) |
| Instrument dimensions | Panel 6.29 in x 3.14 in x (160 mm x 80 mm), opening 5.98 in x 2.99 in (152 mm x 6 mm) |
| Instrument weight | 0.99 lb (450 g) |
