Technical Specifications
| Measurement Range | 0 to 9999 |
| Accuracy | 0.2% FS |
| Channels | 1 to 16 |
| Power Supply | 100 VAC to 240 VAC |
| Print interface | RS 232 C direct connection to micro printer, baud rate 1200 |
| Recording capacity | 64 MB, 128 MB, 1922 MB, 248 MB flash capacity optional |
| Recording interval | 1 to 240 seconds, divided into 11 files 1, 2, 4, 4, 8, 12, 24, 36, 60, 120, 180, 240 seconds. |
| Data backup and storage | Support USB 1.1 USB 2.0 USB disk, support 1 G to 32 GB U disk for data transfer, strong compatibility, compatible with most of the U disk on the market, industrial version recommended |
| Voltage input | 0 V to 5 V, 1 V to 5 V, 0 mV to 20 mV, 0 mV to 100 mV |
| Resistor input | Res 0 Ω to 400 Ω |
| Working Temperature | 32 ℉ to 122 ℉ (0 ℃ to 50 ℃) |
| Weight | 4.41 lb (2 kg) |
