Technical Specification
| Resolution | 800 × 480 pixels |
| Display color | TFT true color |
| Backlight | Long lifespan LED |
| Memory | 150 MB |
| Communication | RS 232, RS 485, Ethernet interface |
| Power supply | 100 VAC to 240 VAC,-15 % to +10 %, 50 Hz to 60 Hz |
| Power consumption | ≤5 W |
| Operating Ambient | Temperature -4 °F to 176 °F (-20 ℃ to +80 ℃) Humidity ≤ 90 % RH |
| Storage temperature | 14 °F to 140 °F (-10 ℃ to +60 ℃) |
| Cooling | Natural |
| Degree of protection | Equivalent to IP65 |
| Accuracy | 0.1 % FS ± 32.18 °F (0.1 ℃) |
| Dimension | 7.99 in x 5.91 in x 1.57 in (203 mm x 150 mm x 40 mm) |
| Net weight | 1.54 lb, 0.0007 ton (0.7 kg) |
