Overview
Hospitality Enviro Tech TCP or IP PoE UHF RFID Integrated Reader can be widely used in logistics tracking, commodity inventory, cargo sorting, vehicle management, personnel management, asset management, medical systems, cold chain management, temperature monitoring, power monitoring, anti-counterfeiting systems and production process control and many other applications.
Features
- Full series of products developed
- Full series of modules UHF chip development
- Whole series of products are modularized
- Whole series of products are supported
- Modules boards have rock-solid stability
- Provide data format personalization.
- Desktop card issuer supports keyboard mode
- Most products support PoE power supply
- Provides multi-OS
- Provide multi-language
- Provide multi-protocol
- Provide OS, language
Technical Specifications
| Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol | ISO 18000-6C |
| LAN | TCP or IP, UDP, PoE, WiFi |
| Antenna | 9 dBi circular polarized |
| Read Distance | 65.6 ft (20 m) |
| SDK | Window, Linux, Android |
| FHSS or Fix Frequency | Support |
| RF Out Power | 30 dBm |
| Step Power | 1 dBm |
| RSSI | Support |
| Reading Distance | ≥ 49.2 ft (15 m) |
| Reading Speed | ≥ 30 per s |
| Baud Rate | 115200 bps |
| Read Value | TID + EPC or USER |
| Mode | Command, polling or trigger |
| Operating Voltage | DC 12.0 V (+9 V to 24 V) |
| Operating Current | ≤ 600 mA or DC 12 V |
| Standby Current | ≤ 100 mA or DC 12 V |
| POE | Support |
| Performance | Common |
| SDK | Support |
| IAP Firmware Update | Support |
| Custom Development | Support |
| Reflector Material | Aluminium |
| Radome Material | ABS + PA757 |
| Radome Color | Black |
| Holding Rod Diameter | Φ 1.5 in X 1.9 in (40 mm to 50 mm) |
| Gain | 9 dBi |
| Polarization | Circular |
| Beam Width (H or V) | Hor: 65 ± 2°or Ver: 65 ± 2° |
| VSWR | ≤ 1.3 |
| Impedance | 50 Ω |
| F or B Ratio | ≥ 25 |
| Max. Power | 50 W |
| Lightning Protection | DC Ground |
| Operating Humidity | < 95 % RH 77 °F (+25 °C) non-condensing |
| Operating Temperature | -4 °F to 140 °F (-20 °C to 60°C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Size | 9.0 in x 9.0 in x 1.5 in (230 mm x 230 mm x 40 mm) |
| Weight | 4.4 lb (2 kg) |
