Features
- Automatic scan Com Port
- Support Firmware Upgrade
- Support Export Config
- Multiple country languages
- Password Mode
- Read specify tag
- Relay
- Data cache
- Multiple communication protocols
- Remote Listening
- RSSI
Technical Specifications
| Frequency | 902 MHz to 928 MHz or 865 MHz to 868 MHz |
| Protocol | EPC Global UHF Class 1 Gen2 or ISO 18000-6 c |
| Interface | RS232 or WG26 or USB or RELAY or TCP/IP (optional) |
| Read Range | 3.2 ft to 32.8 ft (1 m to 10 m) |
| Built-in Antenna | 9 dBi circular antenna |
| Work Mode | Active or trigger or answer or password or mask mode |
| Application | Parking people access warehouse management etc |
| Software Support | Provide SDK, demo software |
| Material | ABS |
| Output Power Range | 0 dBm to 26 dBm |
| Read Range | 3.2 ft to 13.1 ft (1 m to 4 m) |
| Power Supply | 9 V to 36 V |
| Operating Temperature | 14 °F to 131 °F (-10 ℃ to 55 ℃) |
| Storage Temperature | -4 °F to 167 °F (-20 ℃ to 75 ℃) |
| Dimensions | 6.4 in X 6.4 in X 1.1 in (165 mm × 165 mm × 30 mm) |
| Weight | 1.6 lb (0.75 kg) |
