Features
- Stylish design with plastic shell, inspired by “TRANSFORMERS”
- Visual waveform display
- Electromechanical integration design, small volume
- Light weight, easy to use
- Using DSP chip to control and data processing, high speed
- Low power consumption
- 128 x 64 OLED dot matrix display
- Digital or graphic display, highlight no perspective
- Intuitive and rich display information
- Can display all the parameters and graphics
- Compatible with ISO, DIN, ANSI, JIS national standards
- Residual quantity icon, prompting the user to charge
- Continuous working time: more than 20 hrs
- Real-time clock settings and display
- Convenient data recording and storage
- With automatic dormancy
- Automatic shutdown and power saving function
- Multi-info Display: measurement information
- Menu prompt, fault and power switch information indicated
- With PC software, can be connected to a computer and printer
- Optional different sensor, measuring platform
- Mini printer, extension rod and other accessories
- Support OEM Service, high price performance
Technical Specification
| 20 Testing Parameters | Ra, Rz = Ry (JIS), Rq, Rt = Rmax, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rku, Rsm, Rmr, Rx, RPc, Rk, Rpk, Rvk, Mr1, Mr2 |
| Measuring Range | Ra 0.005 μm to 16.000 μm, Rz 0.02 μm to 160.00 μm |
| Sample Length | 0.009 in, 0.031 in, 0.09 in (0.25 mm, 0.80 mm, 2.50 mm) |
| Evaluation Length | 1 L to 5 L |
| Maximum Drive Stroke | 0.68 in (17.5 mm) |
| Indication Accuracy | 0.001 μm |
| Indication Error | ≤±10% |
| Variability | <6% |
| Data Storage | 100 groups |
| Power | Rechargeable Li-battery |
| Relative Humidity | <90% |
| Working Temperature | -4 ℉ to 104 ℉ (-20 °C to 40 °C) |
| Size | 6.2 in x 2.5 in x 1.8 in (158 mm x 63.5 mm x 46 mm) |
| Weight of Host | 10.5 oz (300 g) |
