Features
- Stylish design with plastic shell, inspired by “TRANSFORMERS”;
- Visual waveform display;
- Electromechanical integration design, small volume, light weight, easy to use;
- Using DSP chip to control and data processing, high speed, low power consumption;
- 128×64 OLED dot matrix display, digital / graphic display; highlight no perspective;
- Intuitive and rich display information, can display all the parameters and graphics;
- Compatible with ISO, DIN, ANSI, JIS national standards;
- Residual quantity icon, prompting the user to charge;
- Continuous working time: more than 20 hours;
- Real-time clock settings and display, convenient data recording and storage;
- With automatic dormancy, automatic shutdown and power saving function;
- Multi-info Display: measurement information, menu prompt, fault and power switch information indicated.
- With PC software, can be connected to a computer and printer;
- Optional different sensor, measuring platform, mini printer, extension rod and other accessories;
- Support OEM Service, high price performance.
Technical Specifications
| 20 Testing Parameters | Ra, Rz=Ry (JIS), Rq, Rt=Rmax, Rp, Rv, R3z, R3y, RzJIS, Rsk, Rku, Rsm, Rmr, Rx,
RPc, Rk, Rpk, Rvk, Mr1, Mr2; |
| Measuring Range | Ra: 0.005 to 16.000μm Rz: 0.02 to 160.00μm |
| Sample Length | 0.009 in, 0.0314 in, 0.098 in (0.25 mm, 0.80 mm, 2.50mm) |
| Evaluation Length | (1 to 5) L |
| Maximum Drive Stroke | 0.7 in (17.5 mm) |
| Indication Accuracy | 0.001 μm |
| Indication Error | ≤±10% |
| Variability | <6% |
| Data Storage | 100 groups |
| Power | Rechargeable Li-battery |
| Relative Humidity | <90% |
| Working Temperature | -4 °F to 104 °F (-20 °C to 40 °C) |
| Size | 6.22 in x 2.5 in x 1.81 in (158 mm x 63.5 mm x 46 mm) |
| Weight of Host | 0.6613 lb (0.3 kg) |
| Data Memorize | 7 Groups |
| Operating Conditions | Temperature: 0 °F to 122 °F (0 ºC to 50 ºC)
Humidity: < 80 % RH |
| Power Supply | Built-in Rechargeable Li-ion Battery |
| Dimensions | 5.5118 in x 2.0472 in x 1.8897 in (140 mm x 52 mm x 48 mm) |
| Weight | 0.9259 lb (420 g) |
| Standard Accessories | Main Unit, Standard Sample Plate SSP-100, Standard Sensor SSP-100, Small Screwdriver, Power Adapter, Carrying Case (B09), Operation Manual |
| Optional Accessories | RS-232C Cable with Software, Bluetooth Adapter with Software, Extension Rod SER-150, Groove Stylus SRP-110, Curvature Probe SRP-120, Measurement Stand SRS-1 |
