Technical Specifications
| Recommended PV Module Power Range (W) | 200 W to 1100 W (for 1000 W Inverter) and less than 1300 W (for 1200 W Inverter) |
| DC Input Branch Number | 1 |
| PV No-Load Input Voltage Voc (V) | 55 V to 90 V |
| MPPT Tracking Range (V) | 44 V to 70 V |
| Battery Voltage Suitable For Connection | 48 V or 60 V |
| Battery Start Voltage Settable Range (V) | 47 to 70 V |
| Battery Low Voltage Shutdown Can Be Set Range (V) | 44 V to 69 V |
| Maximum Input Protection Current (A) | 25 A |
| Rated AC Output Power | 1000 W to 1200 W |
| Battery Mode Constant Power (W) |
90 W to 750 W |
| Battery Limit Mode Maximum Output Power |
800 W |
| Maximum Inverter Efficiency | 90 % |
| Maximum AC Current | 10 A or 5 A |
| AC Voltage (V) | 120 V or 230 V |
| AC Voltage Range | 90 to 140 V o 180 to 260 VAC |
| AC Frequency (Hz) | 50 HZ or 60 HZ |
| AC Frequency Range (Hz) | 48 to 62 HZ |
| MPPT Tracking Efficiency | Over 99 % |
| Output Power Factor | Over 0.98 |
| Night Standby Power Consumption | Less than 3 W |
| Output Current Total Harmonic Distortion Rate |
Less than 5 % |
| Island Effect Protection | VAC and FAC |
| Work Status Indication | No LCD display (Chinese or English display can be self-adjusted) and WIFI monitor |
| Protection Function | DC Overvoltage and overcurrent and AC overvoltage and Overcurrent and Over frequency and Over temperature Protection |
| Communication Method | RS485 and limiter sensor equals Grid tie inverter with limiter |
| Machine Size | 12.01 in x 7.48 in x 4.33 in (30.5 cm x 19 cm x 11 cm) |
| Gross Weight | 11.02 lb (5 kg) |
