Overview
Hospitality Enviro Tech soil density meter is suitable for measurement by boiling saturation method, vacuum saturation method, and sealing wax method. Adopt the principle of the animate buoyancy method and read the values directly.
Features
- Digital display and direct reading, without manual calculation
- Direct display density and volume, etc
- Compacted soil, soil particles, and similar products can be quickly measured
- Adopt the original German HBM sensor for accurate measurement
- Simple operation, stability, and durability
- It has the function of actual water temperature compensation
- Can adapt to the change of test environment
- The media liquid density can be set; water
- Other liquid media can be used as the medium
- Adopt integrated forming large capacity measuring platform
- Adopt corrosion resistant and fall resistant, free replacement for life
- Adopt a special windproof dustproof cover
- Makes the structure more convenient and durable
- It can be connected to the PC and printer easily by RS-232
- Optional mz-p1 printer to print the measurement data
Technical Specifications
| Density accuracy | 0.001 g/cm³ |
| Accuracy range | 0.001 g/cm³ to 99.999 g/cm³ |
| Sample range | Soil, concrete, asphalt etc |
| Principle | Archimedes drainage principle |
| Testing time | 10 to 60 seconds |
| Values showed | Volume density (mediator method), apparent density, wet density, apparent porosity, water absorption, open porosity, closed porosity, total porosity, Powder ture density |
| Parameter setting | Water temperature, medium liquid density |
| Calibration mode | One-key automatic correction |
| Output mode | RS-232C standard communication interface |
| Power supply | European Standard AC 100 V – 240 V |
| Optional accessory | MZ-P1 printer and Mini PC |
| Standard documents | Specifications, certificates, warranty CARDS, quick operation instructions, video reference materials |
| Max weight | 1 oz to 10.58 oz (0.005 g to 300 g) |
