Features
- GLP Compliant, auto-calibration, temp compensation, RS232 output
- 7801 Glass sodium ion electrodes for diverse applications
- 6212 Double salt bridge minimizes contamination
- Self-setting calibration, direct ion concentration measurement
- Switch between pX, mol/L, mg/L, ppm
- Standard stirrer, adjustable speed for repeatability
Technical Specifications
| Measurement Range | -1999.9 MV To 1999.9 MV |
| MV Resolution | 0.1 MV |
| MV Accuracy | ±0.03% FS |
| Ion Concentration Measuring Range | PH: 0 PNa To 14 PNa; Supporting Facilities：1.00 PNa To 7.00 PNa |
| Ion Concentration Display Unit | PX, Mol/L, Mg/L, Ppm |
| Ion Concentration Accuracy | PH: ±0.01 PX Supporting facilities：±0.02 PX |
| Ion Concentration Temperature Compensation Range | 32 °F To 140 °F (0 ℃ To 60 ℃) (Automatic Or Manual) |
| Temperature Measuring Range | 14 °F To 230 °F (-10 ℃ To 110 ℃) |
| Temperature Resolution | 32.18 °F (0.1 ℃) |
| Temperature Accuracy | 41 °F To 140 °F (5 ℃ To 60 ℃) Range: ±32.72 °F (± 0.4 ℃) Other Ranges: ±31.52 °F To ±33.44 °F (± 0.8 ℃) |
| Data Storage | 900 Sets |
| Power Supply | DC 9 V Or 300 MA |
| Communication Interface | RS 232 |
| Ambient Humidity | ≤ 75% |
| Ambient Temperature | 41 °F To 95 °F (5 ℃ To 35 ℃) (0.01 Level), 59 °F To 86 °F (15 ℃ To 30 ℃) (0.001 Level) |
| Dimensions | 6.29 In × 7.48 In × 2.75 In (160 Mm x 190 Mm x 70 Mm) |
| Weight | 1.94 Lb (880 g) |
