Technical Specifications
| Display Screen | 7 in (17.78 cm) color touch LCD screen, 800 x 480 resolution |
| Measurement Accuracy | 0.2 FS |
| Alarm Relay | 6-way normally open relay, 250 VAC 3 A, 30 VDC 3 A, resistive load |
| Transmission Output | 8-way 4 mA to 20 mA transmission output, load |
| 24 VDC Power Distribution | 2 channels of 24 VDC ± 10%, total output current |
| Ethernet Communication | One Ethernet communication interface, standard Modbus TCP protocol |
| USB Interface | USB 2.0, support large capacity USB |
| Micro Print Interface | 1-way TTL micro printer interface |
| Power Supply | AC 100 VAC to 240 VAC 50 Hz, DC 24 V DC ±10%, power ≤20 W |
| Preheat Time | 30 min after power on |
| EMC Anti-interference | Power group pulse 2000 V, signal group pulse 1000 V |
| Humidity | 0% RH to 85% RH (no condensation) |
| Working Environment | Temperature 14 ℉ to 140 ℉ (-10 ℃ to 60 ℃) |
| Meter Size | Panel 7.36 in × 5.79 in (187 mm × 147 mm), Opening 5.43 in × 5.43 in (138 mm × 138 mm) |
