Features
- Automatically track high and low temperature
- PC connectivity
- 2-inch TFT display
- Multiple color palettes
- USB 2.0 connectivity
- 5 color imaging models
- Inbuilt infrared
Technical Specifications
| Display Screen | 3.2-inch full angle TFT display screen |
| Infrared Image Resolution | 200 x 160 |
| Visible Image Resolution | 300,000 pixels |
| Field Angle/Shortest Focus Length | 27° × 35° or 1.64 ft (0.5 m) |
| Thermal Sensitivity | 32.1 °F (0.07 °C) |
| Temperature Measurement Range | -13 °F to 842 °F (-25 °C to 450 °C) |
| Measurement Accuracy | ±2% or -4 °F to 35.6 °F (-2 °C to +2 °C) |
| Emissivity | Adjustable from 0.01 to 1.0 |
| Frame Rate of Thermal Images | 9Hz |
| Wavelength Coverage | 8 µm to 14 µm |
| Product Size | 3.5 in × 4.1 in × 8.7 in (90 mm × 105 mm × 223 mm) |
| Product Weight | 0.85 lb. (389 g) |
| Storage Temperature | -40 °F to 140 °F (-40 °C to 60 °C) |
