Technical Specifications
| Nominal Ac Input Voltage/Waveform | 230 Vac |
| Ac Input Range | 90 Vac to 280 Vac (Appliances)
170 Vac to 280 Vac (UPS) |
| Max AC Input Voltage | 300 Vac |
| Nominal Input Frequency | 50 Hz to 60 Hz (Auto detection) |
| Ac Input Frequency Range | 40 Hz to 65 ± 1Hz |
| Output Voltage Waveform | Pure Sine Wave |
| Output Voltage | 220 Vac
230 Vac 240 Vac ± 5% |
| Output Frequency | 50 Hz to 60 Hz ±1 Hz |
| Nominal Battery Input Voltage | 12 Vdc |
| Cold Start Voltage | 11.5 Vdc |
| Low Voltage Cut-Off | 10.2 Vdc |
| High Voltage Cut-Off | 15.5 Vdc |
| No Load Power Consumption | <25 W |
| Dimension | 4.33 in x 11 in x 13.9 in(11 cm x 28 cm x 35.5 cm) |
| Net Weight | 13 lbs (5.7 kg) |
