Features
- High bandwidth
- Arbitrary waveform generator
- Auto measurements
- High real time sample
- 5.7 in (14.47 cm) screen
- LED
- Direct key for each channel
Technical Specification
| Bandwidth | 60 MHz |
| Channel | 2 |
| Real-Sample Rate | 250 MSa/s |
| Equivalent Sample Rate | 50 GSa/s |
| Record Length | 32 K |
| Rish Time | ≤5.8 ns |
| Time Base Accuracy | ±50 ppm |
| Time Base Range | 5 ns/div to 1000 s/div |
| Input Impendence | 1 MΩ ΙΙ 15 pF |
| VOLTS or DIV Range | 10 mV/div to 5 V/div |
| A or D Converter | 8 bit |
| Bandwidth Limit | 20 MHz |
| Waveform Frequency | 25 MHz |
| DAC Clock | 2 K to 200 MHz adjustable |
| Frequency Resolution | 0.10% |
| Waveform Depth | 4 KSa |
| Vertical Resolution | 12 bit |
| Frequency Stability | <30 ppm |
| Waveform Range | ±3.5 V Max. |
| Output Impedance | 50 Ω |
| Output Current | 50 mA Ipeak = 50 mA |
| System BW | 25 M |
| Harmonic Distortion | -50 dBc (1 KHz), -40 dBc(10 KHz) |
| Frequency Range | 60 MHz |
| Input Range | 400 mVpp to 18 Vpp |
| Max. Input Impendence | 10 MΩ |
| Display | 5.7 in (14.47 cm) |
| Display Resolution | 320 pixels x 240 pixels |
| Dimension | 9.64 in x 6.41 in x 2.04 in (245 mm x 163 mm x 52 mm) |
| Weight | 2.86 lb (1.3 kg) |
