Features
- With multi-coil technology, the rebar position can be located more real-time and accurately
- Rebar position, spacing and cover thickness are displayed on the same screen
- USB data transmission
- Up to 65m for profile and grid scan modes and up to 10m for signal scan mode
- Two data view mode
- Graph and list, which enables convenient and flexible operation as well as quick view of the data
- Data transmission
- Five scan modes are provided to suit for different measuring environment
Technical Specifications
| Applicable range | 0.236 in to 1.96 in (6 mm to 50 mm) |
| cover thickness range | 0.078 in to 7.87 in (2 mm to 200 mm) |
| Power | Built-in chargeable lithium battery |
| Color | Red |
| Battery time | more than 38 hrs |
| Test accuracy | 0.0039 in (0.1 mm) |
| Data transmission | USB |
| Weight | 11.023 (5 kg) |
