Features
- The surface hardness of sand mold is divided into three types
- Suitable for the surface hardness test of fine sand mold or core
- Manual or mechanical low and medium pressure molding
- Suitable for the surface hardness test of fine
- Coarse sand mold or core in manual or mechanical low
- Medium pressure molding
- Suitable for the surface hardness test of sand mold in high pressure
- The unit of type B hardness tester for sand mold surface is (g or mm2)
- But it is customary to use hardness H (A or B or C) instead of unit
- Because their values are related and consistent
- The corresponding hardness value is also large
- When the unit value is large (g or mm2)
- With average calculate function
- Peak value deposit function
- Under-voltage alarm function
- Use USB data output to connect with PC
- Provide Bluetooth data output choice
Technical specification
| Stroke | 0.09 in (2.50 mm) |
| Shape and size of indenter | Spherical R2.50, Spherical R12.70, Spherical R1.20 |
| Unit | HA, HB, HC |
| Display | 4 digits, 0.39 in (10 mm) LCD |
| Parameters | Tested Result or Mean Value or Max. Value |
| Display Range | 0 H to 100 H (A or B or C) |
| Testing Range | 10 H to 90 H (A or B or C) |
| Accuracy | ≤ ±1 H (A or B or C) |
| Power Supply | 2 x 1.5 V AAA (UM-4) Battery |
| Resolution | 0.1 H (A or B or C) |
| Battery Indicator | Low Battery Indicator |
| Operating Temperature | 32 ℉ to 104 ℉ (0 ℃ to 40 °C) |
| Operating Humidity | < 80% RH |
| Load | 8.3 oz, 34.5 oz, 52.9 oz (237 g, 980 g, 1500 g) |
| Pressure Load | 3.1 oz, 1.7 oz, 6.3 oz (90 g, 50 g, 180 g) |
| Dimensions | 6.3 in x 2.5 in x 1.1 in (162 mm x 65 mm x 28 mm) |
| Weight | 5.9 oz (170 g) |
