Features
- LCD Display
- Explosion Proof
- OEM or ODM Acceptable
Technical Specification
| Measure Parameters | Refractive index(nD), Brix (%), Temperature (° C) |
| Measure range | 0% to 15%, 0% to 33%, 0% to 53%, 93% |
| Min Resolution Ratio: | Brix: 0.1% (Range for 15%, 33% & 53%), Brix: 0.5 % (Range for 93%) |
| Measurement Accuracy | Brix: ±0.1%, Brix: ±0.3% (standard) |
| Operating current | ≤200 mA |
| Display menu | Refractive index(nD), Brix (%), Temperature (° C) |
| Output | 4 mA to 20 mA, 4 mA to 20 mA + RS485 optional |
| Power | 12 V to 24 V DC |
| Wetted parts material | Prism: sapphire, Prism stage: SS304, SS316L |
| Optical source | LED (the wavelength approximately to D line) |
| Max Pressure | 1 MPa |
| Protection grade | IP67 |
| Process connection | 3” tri to clam, other size supply free adaptor |
| High and low limit settings | Buttons can be set |
| Recorder output cable | 2 M,3 M,5 M,10 M optional |
| Temperature sensor | Thin film platinum sensor |
| Environment Temperature | 32 °F to 104 °F (0 ° C to 40 ° C) |
| Weight | 11.02 lb (5 kg) |
