Features
- Infrared thermal imaging camera
- Free computer web application
- Power consumption
- Imaging algorithm depth optimization
- Small capacity and limited space
- Thermal image camera VS traditional temperature monitoring
Technical Specifications
| Detector type | Uncooled vanadium oxide VOX Focal plane |
| Detector resolution | 256 pixel x 192 pixel |
| Thermal sensitivity | ＜60 MK |
| Frame rate | 25 Hz |
| FOV | 42° x 32.1° |
| Focusing | Focus |
| Color palette | at least 6 color palettes |
| Visible light resolution | 1920 pixel x 1080 pixel |
| Light supplementary | Built-in LED light |
| Alarm function | All temperature measurement points, areas etc….temperature and average temperature can configure separately alarm output. |
| Protocol, standard | ONVIF, GB, 28181, MODBUS |
| Mobile format | MJPEG, H.264 |
| Manual, automatic adjust | Support |
| Storage medium | Built-in saver, TF card maximum memory 64 G |
| Picture storage mode | Infrared, visible light separate, simultaneous, Fusion |
| File format | JPEG, MP4 |
| B, S configuring interface | Available |
| C, S configuring interface | Available |
| SDK | Output externally origin temperature data Support SDK for user secondary development |
| Power supply | DC 12 V |
| Video interface | Analog video |
| Network interface | including 10 M, 100 M adaptive ethernet port and POE power supply |
| Alarm interface | Alarm IO interface |
| Resolution | 1920 x 1080 |
| Visible light fusion | Dual wave image fusion enhances |
| Accuracy | ±35.6 °F (±2 ℃) or reading 2% |
| Point, line, Area | 6 removable points, 1 line, 6 removable areas |
| Preset | Available |
| Protection level | IP 67 |
| Working temperature and humidity | -68 °F to 140 °F (-20℃ to 60 ℃), ≤95% No condensation |
| Storage temperature and humidity | -104 °F to 158 °F (-40 ℃ to 70 ℃), ≤95% No condensation |
| Range | -68 °F to 248 °F (-20 ℃ to 120 ℃) |
| Dimension | 2.12 in x 0.98 in x 3.11 in (54 mm x 25 mm x 79 mm) |
