Features
- User friendly dialog interactive helps operations like Calibration, making curves, etc.
- All tools you need: DAC, AVG, TCG, AWS
- Pulse Repetition Frequency: 20-2000Hz precise adjust, high speed scan, no miss out
- High Signal to noise ratio, clear and stable echo, anti-noise design, perfect for tough working conditions
- 12-digit AD, high speed sampling leads to better echo diagram with all details. Sensitive and can detect even tiny flaws
- Can use probe frequency 20M perfectly
- High speed real-time flaw detection video recording. Unlimited USB data storage
- IP65 standard. Alloy + Silica gel case, water and dust proof, solid and lasts forever.
- Damping support makes it stand in any angle
- The battery lasts 15 hours for one charge.
- Each battery has own charging control so with two batteries it can work around the clock
Technical Specifications
| Range | 0 in to 393.7 in (0 mm to 10000 mm), at steel velocity |
| Material Velocity | 100 m/s to 20000 m/s |
| Pulse Repetition Frequency | 20 Hz to 2000 Hz |
| Dynamic Range | ≥ 38 dB |
| Resolving Power | > 40 dB (5P14) |
| Sensitivity Leavings | > 66 dB |
| Power Requirements | AC Mains 100 V to 240 V AC, 50 Hz to 60 Hz |
| Dimensions | 9.45 in x 5.91 in x 1.97 in (240 mm × 150 mm × 50 mm) |
| Operating Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Storage Temperature | -22 °F to 122 °F (-30 ℃ to 50 ℃) |
| Weight | 3.1 lbs. (1.4 kg) |
