Features
- Selectable analog bandwidth of 20 MHz
- Low-frequency response (-3 db), <10 Hz at BNC
- DC gain accuracy of 3% for average acquisition mode
- ±4% for average acquisition mode
- Normal, peak detect, average, and HR acquisition mode
- Up to 2000 waveforms per second per channel acquisition rate
- Trigger mode of auto or normal
- Trigger level accuracy of CH1 to CH4 divisions
- Edge, pulse, width, video, slope, overtime, window, pattern trigger type
- Delta V voltage difference between cursors
- Delta T time difference between cursors
- Reciprocal of delta T in hertz (1 per Delta T)
Technical Specifications
| Amplitude | 5 mV to 3.5 Vp p (50 Ω): 10 mV to 7 Vp p (high impedance) |
| Display Type | 7-inch 64 K color TFT (diagonal liquid crystal) |
| Display Resolution | 800 horizontals by 480 vertical pixels |
| Output Voltage, Typical | About 2 Vpp into ≥1 MΩ load |
| Frequency, Typical | 1 kHz |
| Supply Voltage | 100 V AC RMS to 120 V AC RMS (±10%).45 Hz to 440 Hz,120 V AC RMS to 240 V AC RMS (±10%).45 Hz to 66 Hz |
| Power Consumption | <30 W |
| Fuse | T, 3.15 A, 250 V, 0.2 in x 0.79 in (5 mm x 20 mm) |
| DAC | 2 K to 200 MHz adjustable |
| Frequency Resolution | 0.001 |
| Waveform Path | 4 k |
| Vertical Resolution | 12 bits |
| Frequency Stability | <30 ppm |
| Dimensions | 16.5 in x 9.4 in x 11.8 (420 mm X 250 mm X 300 mm) |
| Weight | 6.39 Ib (2.90 Kg) |
