Features
- Automated calibration of transducer Zero Offset or Velocity.
- Automated gain, Peak Hold and Peak Memory.
- Automated display precise flaw location (Depth d, level p, distance s, amplitude, sz dB, ф).
- Automated switch (Depth d, level p, distance s).
- 100 independent setups, any criterion can be input freely, we can work in the scene without test block.
- Big memory of 300 A graph.
- Gate and DAC alarm; Acoustic-Optical alarm.
- RS232/USB port, easy to connect with pc.
- The embedded software can be online updated.
- Li battery, continue working time up to 10 hours.
- Display freeze.
- Automated echo degree.
- Angles and K-value.
- Lock and unlock function of system parameters.
- Electronic clock calendar.
- Two gates setting and alarm indication.
- High-speed capture and very low noise.
- Automatically calculate the size of the flaw with wide bottom type in AVG function.
Technical Specifications
| Measuring Range | 0 in to 36.2 in (0 mm to 6000 mm) |
| Gain | 0 dB to 100 dB |
| D-Delay | -20 µs to 3400 µs |
| Resolution | 0.004 in (0.1mm): 0.01 in to 3.9 in (2.5 mm to 100 mm) 0.04 in (1mm) (>100) |
| P-Delay | 0 µs to 99.99 µs |
| Material Velocity | 1000 m/s to 9999 m/s |
| Temperature | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Humidity | 20% RH to 90% RH |
| Power | 7.4 V 4800 mAh |
| Working Time | > 8 hours |
| Display | LED true color |
| Size | 9.37 in x 6.3 in x 1.97 in (238 mm x 160 mm x 50 mm) |
| Weight | 2.2 lbs. (1.0 kg) |
