Features
- The dual CPUs work in coordination, high speed detecting and data processing;
- Automatic calibration
- Easy tests of thickness and sound velocity of materials
- Freely set standards for various industries to meet different flaw detection
- Automated display precise flaw location (Depth, level, distance, amplitude, dB, diameter)
- Freely set standards for various industries to meet different flaw detection
- The echo suppression is adjustable from 0% to 90%, without affecting the dB gain and linearity
- DAG and AVG(DGS) curves are generated automatically
- Muti-functions for easy detection: peak memory, Display freeze, automatic gain & wave search;
- Li -battery, continue working time up to 10 hours;
- Storage: 500 sets of flaw detection process and data storage;
- Provides high contrast viewing of the waveform from bright, direct sunlight to complete darkness and easy to read from all angles;
- USB connects to computer, automatically generate flaw detection report
Technical Specifications
| D-delay (Ms) | 0 ms to 5000 ms |
| Range Of Scanning (mm) | 0 mm to 1000 mm |
| Working Mode | Single probe (receiving and sending), double probe (one for receiving and another for sending), transmission (transmission probe) |
| Frequency Range (MHz) | 0.5 MHz to 10 MHz |
| Gain Adjustment (dB) | 0 dB to 110 dB |
| Reject | 0% to 80% of screen height |
| Vertical Linear Error | Vertical linear error is not more than 3% |
| Horizontal Linear Error | Not more than 0.1% in the scanning range |
| Sensitivity Leavings | ≥50 dB |
| Dynamic Range | ≥36dB |
| Alarm | Three modes, i.e. forbidden wave, loss wave and auto |
| A-Scan Display Area | Full screen or local A-Scan display freezing and de-freezing A-Scan filling |
| Standard Communication Interface With PC | USB |
| Battery | Li-battery: 3.6V 3000 mAh |
| Power Adaptor | 4.2 V DC 220 AC |
| Working Temperature | -20 ℃ to 50 ℃ ( |
| Working Humidity | 20% to 90% |
| Overall Dimension (Mm) | 6.38 in x 4.13 in x 1.65 in (162 mm ×105 mm × 42 mm) |
| Weight (Kg) | 1.49 lb. (680 g) |
