Overview
Hospitality Enviro Tech portable IR Thermal Imaging Camera is a newly released Professional InfraRed 33 x 33 pixels Imager Thermometer with 2.4-inch color TFT LCD display. It can be widely used in the power industry, industrial testing, fire safety, petrochemical, automotive testing, aerospace, building energy saving, transportation applications, scientific research and development, agricultural ecology etc.
Features
- 4-inch TFT color LCD display
- Adjustable emissivity from 0.1 to 1.0
- Visual/heat map image alignment
- Image capture and save in SD card
- Higher Image refresh rate than others
- Tough trigger lock design
Technical Specifications
| IR Resolution | 33 x 33 pixel |
| Temperature Range | -4 °F to 716 °F (-20 °C to 380 °C) |
| Accuracy | 28.4 °F to 35.6 °F (-2 °C to 2 °C) or ±2% of reading |
| Display | 2.4-inch TFT 320 x 240 Pixels color |
| Visible Camera | 300,000 pixels |
| Field of View (FOV) | 33° x 33° |
| Best Focus Distance | 1.64 ft (0.5 m) |
| Thermal Sensitivity | 32.27 °F (0.15 °C) |
| Emissivity | 0.10 to 1.0 adjustable |
| Spectral Range | 8 µm to 14 µm |
| Color Palettes | Iron color, rainbow and gray |
| Image Capture Frequency | 9 Hz |
| Focus Mode | Fixed |
| Image Storage | SD Card (Micro TF) 8GB |
| File Format | Bmp |
| Battery Type | 4 x 1.5 V “AA” size Lithium battery |
| Battery Life | 6 hours |
| Timed Shutdown Time | Choose-able |
| Working Conditions | 23 °F to 104 °F (5 °C to 40 °C) 10% RH to 80% RH |
| Storage Conditions | -4 °F to 122 °F (-20 °C to 50 °C) 10% RH to 80 RH |
| Item Size | 10.2 in x 7.8 in x 4.0 in (260 mm 200 mm x 102 mm) |
| Item Weight | 0.66 lb. (0.3 kg) |
