Hospitality Enviro Tech Portable Infrared Gas Analyzer

Hospitality Enviro Tech Infrared Gas Analyzer belongs to the non-spectral infrared gas analyzer. Its working principle is based on some gas’ selective absorption of infrared, adopts imported infrared sensors and advanced digital processing technology, to achieve the online continuous measuring of CO, CO2, CH4, SO2, NOx, NH3, H2S, etc.

SKU: HETCMGD-316 Category:

Features

  • 128 x 64 LCD monitor, easy installation
  • Imported infrared sensors for high sensitivity
  • Long-lasting lithium battery with auto-voltage protection
  • Data backup and recovery
  • Full English operation menu



Technical Specifications

Measuring range 0 ppm to 1000 ppm/100%
resolution  0.1 ppm /1ppm /0.01% /0.1%
Accuracy  ≤±2% F.S
Repeatability ≤±1% F.S
Zero drift ±1% F.S/7 d
Span drift ±1% F.S/7 d
Response time T 90≤30 s
Warm-up time ≤45 min
Sample gas flow rate 1000 mL/min ±100 mL/min
Sample gas pressure 14.50 PSI (100 kpa)≤entrance pressure ≤29.01 PSI (200 kpa)
Power Supply 100 V to 240 V AC 50 Hz to 60 Hz 1A
Ambient temperature 23 °F to 113 °F (-5 ℃ to +45 ℃)
Environment humidity ≤90% RH
Dimensions 10.24 in x 5.71 in x 12.99 in (260 mm x 145 mm x 330 mm)
Weight 7.72 lb (3.5 kg)
