Features
- Colour high contrast LCD touchscreen, 7.0 inches
- Intelligent operation system
- Multi reading feature allows auto read, timed read and continuous read
- Automatic or manual temperature compensation
- Data Storage 1000 sets for each parameter (GLP compliant)
- Data analysis feature helps user review, compare and recalculate results
- Support for USB or RS-232 communication
- Reset feature automatically resumes all settings back to factory default options
- IP54 waterproof
- 1 point to 6 points calibration with standard recognition
- Selectable pH buffer groups, including NIST, DIN, GB
- Support for pH standard group customization
- Automatic electrode diagnosis with pH slope and offset display
- 1 point to 6 points calibration
- Selectable measurement unit
- Multi-measurement modes are supported
- Over 10 methods are built in
- User defined method is supported
Technical Specifications
| Range | -2.000 pH to 20.000 pH |
| Resolution | 0.1 pH, 0.01 pH, 0.001 pH |
| Accuracy | ± 0.002 pH |
| Calibration Points | Up to 6 |
| Standard Recognition | NIST, GB, DIN buffers |
| Range | -2000.00 mV to 2000.00 mV |
| Resolution | 0.1, 0.01 mV |
| Accuracy | ± 0.1 mV or ± 0.03 % |
| EH ORP Mode | Yes |
| ORP Calibration Points | 1 custom point to 2 custom point (relative mV) |
| Range | -2.000 pX to 20.000 pX |
| Resolution | 0.1 pX, 0.01 pX, 0.001 pX |
| Accuracy | ± 0.002 pX |
| Calibration Points | Up to 6 |
| Range | 0 to 19990 |
| Resolution | Up to 4 significant digits |
| Accuracy | ± 0.3 % |
| Calibration Points | Up to 6 |
| Reading Mode | Auto read (fast, medium, slow), timed, continuous |
| Reading Prompts | Reading, stable, locked |
| Temp. Compensation | ATC, MTC |
| Data Storage | 1000 Groups |
| PH Electrode | BNC(Q9) |
| USB, RS 232 | USB 2.0 flash memory device, printer, PC |
| Auto Shutdown | 1 min to 60 min, off |
| IP Rating | IP54 |
| Power | AC adapter, 100 V to 240 V AC input, DC24 V output |
| Temperature Resolution | 0.1 |
| Temperature Accuracy | ± 0.1 |
| Temp Probe | 6 pin mini DIN |
| Temperature Range | 41 °F to 266 °F (5 ºC to 130 ºC) |
| Dimensions | 11.02 in x 11.02 in x 5.11 in (280 mm × 280 mm ×130 mm) |
| Weight | 5.51 lb (0.25 kg) |
