Features
- Center rod is made from imported material
- High Aluminum case extend use life
- High accuracy and durable resistance
- Pointer slider is outside structure
- Its friction can be balance well
- Easy to be adjusted
- We can make sure that the instrument is accurate
Technical Specification
| Standard impact energy | 2.207 ±0.1 J (0.225 Kgf.m) |
| The static friction of pointer slider | 0.65 N ±0.15 N |
| Length of spring stretch | 2.9 in, 0.011 in (75 mm, ±0.3 mm) |
| Average rebound hammer on steel anvil Rm | 80, ±2 |
| Measuring Range | 10 Mpa to 60 Mpa |
| Radius of spherical tip | 0.98 in, ±0.03 in (25 mm, ±1 mm) |
| Working Temperature | 14 ℉ to 122 ℉ (-10 ℃ to +50 ℃) |
| Working Humidity | ≤ 90% RH |
| Dimensions | 2.1 in x 11 in (Φ 54 mm x 280 mm) |
| Net weight | About 2.2 lb (1 Kg) |
