| Vertical Analog Channels |
4 |
| Vertical Bandwidth |
100 MHz |
| Vertical Rise Time |
3.5 ns |
| Vertical Input Impedance |
Resistance: 1 MΩ; Capacitance: 25 pF |
| Vertical Input Sensitivity |
1 mV/div to 10 V/div |
| Vertical Input Coupling |
AC or DCn or GND |
| Vertical Resolution |
8 bits |
| Vertical Memory Depth |
1.6 K to 128 M/CH |
| Vertical Max. Input Voltage |
400 V (DC + AC Peak) |
| Horizontal Real-Time Sampling Rate |
1 GSa/s |
| Horizontal Time Base Range |
2 ns/div to 1000 s/div |
| Horizontal Time Base Precision |
±50 ppm |
| Horizontal Source |
CH1, CH2, CH3, CH4, EXT, EXT/10 |
| Horizontal Mode |
Edge, Pulse, Video, Slope, Timeout |
| Type |
Signal, Auto, Normal |
| Horizontal Auto Measurement |
Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle |
| Horizontal Cursors Measurement |
Horizontal, Vertical, Cross |
| Horizontal Waveform Signal Process |
+, -, x, ÷, FFT, Invert |
| Horizontal Voltage Range |
1 mV to 10 V/div @ x 1 probe; 10 mV to 100 V/div @ x 10 probe |
| 100 mV to 1 KV/div @ x 100 probe; 1 V to10 KV/div @ x 1000 probe |
| Horizontal FFT |
Rectangular, Hanning, Hamming, Blackman Window |
| Function/ARB. Waveform Generator Interface |
USB 2.0 |
| Function/ARB. Waveform Generator Power Supply |
8 V to 36 V Wide range of input voltage, suitable |
