Features
- Universal input
- Programmable
- Photoelectric isolation
- Various process parameters
- USB or TF card
- 8 GB for data transfer
- RS 485 or ethernet
- Modbus
- Powerful pc software
Technical Specifications
| Accuracy | ±(0.2% FS 1) digital |
| Power Supply | 100 V AC to 260 V AC |
| LCD Size | 3.5 in (88.9 mm) TFT Color LCD Display |
| Universal Input | Thermocouple, RTD, Analog 4 ma to 20 ma, 0 ma to 10 ma, 0 V to 5 V, 0 V to 10 V, 1 V to 5 V, 0 V to 500 mV |
| Input Channels No. | 1 Channels to 16 Channels |
| Isolation | 400 V AC photoelectrical isolation between channels |
| Sample Rate | 1 s per 1 channel |
| Relay | Max 16 relay output |
| Communication | RS 485 standard MODBUS RTU protocol |
| Communication | Ethernet standard MODBUS TCP or IP protocol |
| Feed Output | auxiliary 24 V DC output for transmitter |
| Flow totalizer | with temperature, pressure compensation, math |
| Memory Capacity | Memory capacity can be set flexibly according to the memory interval time setting Huge capacity for long time data saving up to 10 years with power off protection |
| Memory Interval time | 1 s, 2 s to 3600 s, can be set flexibly as required in recorder |
| Screen Display | Various screen display in digital, trend, barograph, circular chat display |
| PC software | Powerful software function to display memorized data in digital curve, print data and export the data to excel for further analysis |
| Size | 6.30 in × 3.15 in × 5.51 in (160 mm x 80 mm x 140 mm) |
