| Power Supply |
AC 85 V to 265 V, DC 24 V to 110 V (optional) |
| Power Consumption |
≤5 V A (actual power consumption is related to the numbers of channel) |
| Numbers of Channel |
1 to 12 channels (analog input:1 to 12 channel, pulse input 2-4 channel optional） |
| Input Signal |
Thermocouple: K, E, R, B, N, T, E, J, S, WRE5-26, WRE-25Thermal resistor: Pt100，Pt1000Current:4 to 20 mA, 0 to 10 mAVoltage:0 to 5 V, 0 to 10 V, ±20 mV, ±100 mV |
| Switch Input |
2 to 4 channels (optional) could collect switch IO current status, Switch IO frequency (0 to 15 K Hz), switch IO accumulative number, Maximum is |
| Channel Isolation Voltage |
420 V |
| Recording Frequency |
1 to 9999 s self-setup |
| Recording Memory (Built-in 8G TF Disk) |
Over 2000 days (12 channel, recording interval per minute) |
| Recording Mode |
Cycle record |
| Alarm Type |
Upper and lower alarm output, each channel with 4 modes (ultimate upper limit value, upper limit value, lower limit value, ultimate limit value) |
| Relay |
2 to 4 channel normal open relay DC 30 V, 1A |
| Wired Communication |
Standard RS 485, MODBUS RTU communication protocol, Ethernet MODBUS TCP protocol |
| Body Material |
Fireproof ABS |
| Operation Environment |
-68 °F to 140 °F (-20 ℃ to 60 ℃), 0 to 95% RH |
| Installation Opening Hole Size |
3.62 in x 3.62 in (92 mm x 92 mm) |
| Product Dimension |
3.62 in x 3.62 in x 4.01 in (96 mm x 96 mm x 102 mm) |
