Features
- Four wire resistive touch screen
- Powerful image display
- Data processing function
- Hidden embedded portable shape
- Long term information collection
Technical Specification
| AC or DC power | 85VAV~265VA/24VDC±10% |
| Power waste | ≤25VA (The instrument input channel number affects actual power waste) |
| Channel number | 1-64 |
| Thermocouple | K,E,R,B,N,T,E.J,S,WRE5 26,WRE3 25 |
| Hot resistance | Pt 100, Cu 50 |
| Current | 4 mA to 20 mA,0 mA to 10 mA,0 mA to 20mA |
| Voltage | 0 V to 5 V,0 V to 10 V,1 V to 5 V |
| Measurement accuracy | ≤± 0.2 %F.S |
| Recording rates | 1 to 19999s |
| Recording model | loop record |
| Alarm type | free to set upper and lower limits for each channel alarm , 4 alarms each channel |
| Relay | TP 1718 |
| Distribution | 24 VDC each channel |
| Operating temperature | 32 °F to 122 °F (0 ℃ to 50 ℃) |
| Operating humidity | <85 %R.H |
| Storage temperature | -4 °F to 158 °F (-20 ℃ to 70 ℃) |
| Materials | ABS |
| Storage humidity | < 95 %R.H |
| Panel cut out | 10.94 in x 10.94 in (278 mm x 278 mm) |
| Dimensions | 11.34 in x 11.34 in x 7.87 in (288 mm x 288 mm x 200 mm) |
| Weight | 8.38 lb, 0.004 ton (3.8 kg) |
