Technical Specifications
| Channel | 8 Channels Not isolated, 12 Channels Isolated |
| Sampling period | 1 sec |
| Record paper | Folding industrial thermal paper, 120 mm wide, 8 meters long |
| Paper speed | 0.39 in/h to 17.72 in/h (10 mm/h to 450 mm/h) |
| Power supply | 100 V AC to 240 V AC 50 Hz to 60Hz, 24 V DC ±10% 45 W |
| Installation | Panel mounting, indoor |
| Relays | 250 V AC 3 A, 30 V DC 3 A (Normal open, Resistive load) |
| 24VDC Output | 24 V DC ±10% 60 mA |
| Offset | MAX 0.08 in (2mm) |
| Panel thickness | 0.08 in to 0.47 in (2 mm to 12 mm) |
| Storage environment | -4 ℉ to 176 ℉ (-20 ℃ to 80 ℃) 0% RH to 85% RH (no condensation) |
| Work environment | 50 ℉ to 140 ℉ (10 ℃ to 60 ℃), 0% RH to 85% RH (no condensation) Preheating time 30 min after power on |
| Dimension | 5.67 in × 5.67 in × 9.17 in (144 mm × 144 mm × 233 mm) |
| Weight | 6.61 lb. (3 kg) |
