Features
- Digital sensor, RS-485 output, support MODBUS
- With automatic cleaning brush to eliminate the impact of oil on the measurement
- Eliminate the effects of ambient light on measurements with unique optical and electronic filtering techniques
- Unaffected by suspended solids in water
- Minimal Maintenance
- Reduced Laboratory Testing
- High Sensitivity and Selectivity
Technical Specifications
| Principle | 90° scattered light |
| Range | 0 to 1000 NTU |
| Precision | 0.1 NTU |
| Resolution | <5% or 0.3 NTU |
| Protection level | Ip68 |
| Output signal | Support RS-485, MODBUS protocol |
| Installation | Submersible type, Circulation type |
| Power supply | DC 5 to12 V, current <50 mA (when not cleaned) |
| Size | 45 mm x 175.8 mm |
| Probe cable length | 10 meters (default), can be customized |
