Overview
This Ophthalmic Auto Refractometer Handheld has an axis angle of 0° to 180°, cylinder of -6.00 D to +6.00 D and sphere -19.00 D to +16.75 D.
Features
- Data transmission with an auto refractometer and auto projector
- Built-in LED for near-vision illumination
- 0-inch color LCD touchscreen
- Stylish and compact design
- Auto detachment printer
- Independent PD adjustment
Technical Specifications
| Sphere | -19.00D to +16.75D |
| Cylinder | -6.00D to +6.00D |
| Axis Angle | 0° to 180° |
| Pupillary Distance | Distant range: 2.04 in x 3.14 in (52 mm to 80mm) Close range: 1.96 in x 3.14 in (50 mm to 80mm) |
| Rotary Prism | 0 to 20 |
| Cross Cylinder Lens | ±0.25 D |
| Plane Retinoscope | +1.50 D |
| Auxiliary Lens | PH Binoculus(1.0mm) RMV, RMH RL (Right eye), GL (Left eye) Polaroid (Right eye 135°/45°; Left eye 45°/135°) Prism (Right 6BU, Left 10BI) Cross Cylinder Lens (±0.50D Axis=90°) PD Lens |
| Phoropter Size | 365mm×280mm×110mm 8.37 lb (3.8 kg) |
| Keyboard Size | 230mm×195mm×190mm 2.64 lb (1.2 kg) |
| Power Box Size | 236mm×126mm×115mm 4.62 lb (2.1kg) |
| Power Supply | AC 220V 50HZ or AC 110V 60HZ,90W |
| Net Weight | 15.65 lb. (7.1Kg) |
