Technical Specifications
| Rated Input | 26 V plus or minus 0.5 V |
| Output Voltage | (110 V or 230 V) and plus or minus 5 % |
| Frequency | (50 Hz plus or minus 2 Hz) or (60 Hz plus or minus 2 Hz) |
| Waveform | Pure sine wave |
| Output THD | THD less than or equal to 3 % (pure resistive load) |
| Output Capacity | 5000 W |
| Peak Power | 10000 W |
| No-Load Current | Less than or equal to 0.6 A |
| USB Output | 5 V and 2.1 A |
| Over Capacity Protection | 5300 W 5 % |
| Over Temperature | 167 °F plus or minus 41 °F (75 °C plus or minus 5 °C) |
| Input Range | (19 to 31 V) and plus or minus 0.5 V |
| Under Volt Alarm Voltage | 21 plus or minus 0.5 V |
| Under Volt Protection Value | 19 V plus or minus 0.5 V |
| Over Volt Protection Range | 31 plus or minus 0.5 V |
| Under Volt Protection Range | 24 plus or minus 0.5 V |
| Over Volt Recovery Voltage Range | 28 V plus or minus 0.5 V |
| Under Volt Protection Alarm | 2 seconds sound continued. Alternately synchronized traffic lights |
| Over Volt Protection Alarm | Two consecutive beeps stop for 1 S and the red and green lights alternately synchronized |
| Over Capacity Protection | Continuous alarm and LED flashes red and continuous startup 2 times and shutdown and manual reset |
| Over Temperature Protection | 3 consecutive beeps stop for 1 S and the red and green lights are alternately synchronized |
| Short Circuit Protection | Short circuit protection without damaging |
| Inverter Efficiency | 89 % |
| Input Voltage | 24 VDC |
| Output Voltage | 230 VAC |
| Output Current | 1 to 50 A |
| Efficiency | Over 90 % |
| Working Temperature | – 40 °F to 122 °F (- 40 °C to 50 °C) |
| Size | 23.23 in x 14.37 in x 21.54 in (59 cm x 36.5 cm x 54.7 cm) |
| Weight | 19.62 lb (8.9 kg) |
