Features
- Lithium battery auto-restart function and more convenient for Lithium battery charging
- Intelligent power supply mode and intelligent distribution of solar panel or mains or battery power ratio
- Mains charging voltage or PV charging voltage is intelligently adjustable and accurately matching various battery charging requirements
- Slim body and convenient installation and transportation
- Battery reverse connection protection with fuse switch and safer installation
- Support working without battery and reduce solar system cost
- Parallel function up to maximum 9 units and enlarge more loads
- Communication options are external WIFI and supervise at any time
- High output voltage accuracy and plus or minus 5 % care for your electrical appliances
Technical Specifications
| Nominal Voltage | 208 VAC or 220 VAC or 230 VAC or 240 V AC |
| Voltage Range | 154 VAC to 264 V AC plus or minus 3 V (Normal Mode)185 VAC to 264 V AC plus or minus 3 V (UPS Mode） |
| Frequency Range | 50 Hz or 60 Hz (Adaptive) |
| Rated Power | 5000 W |
| Output Voltage (AC) | 208 or 220 or 230 or 240 V AC plus or minus 5 % |
| Output Frequency | 50 Hz or 60 Hz plus or minus 0.1 % |
| Waveform | Pure sine wave |
| Transfer Time (Optional) | 10 minutes for computer20 minutes for home appliances |
| Peak Power | 10000 VA |
| Peak Efficiency (Battery Mode) | More than 94 % |
| Inverter Efficiency | More than 98 % |
| Rated Voltage | 48 VDC |
| Constant Voltage Charging Voltage (Optional) | 56.4 VDC |
| Floating Charge Voltage (Optional) | 54 VDC |
| PV Charging Method | MPPT |
| PV Max Input Power | 5500 W |
| MPPT Tracking Range | 120 to 430 Vdc |
| Max PV Input Voltage | 500 Vdc |
| Max PV Charging Current | 100 A |
| Max AC Charging Current | 100 A |
| Max Charging Current | 100 A |
| Rs 232 | 5 PIN or Pitch 0.08 in (0.2 cm) and baud rate 2400 |
| Expansion And Configuration Port | 2 5 PIN or Pitch 0.1 in (0.25 cm) and lithium battery BMS communication card and WIFI card and dry contact card and etc |
| Parallel Interface | Yes |
| Size | 22.24 in x 15.08 in x 7.4 in (56.5 cm x 38.3 cm x 18.8 cm) |
| Weight | 26.5 lb (12 kg) |
