Overview
Hospitality Enviro Tech Ultrasonic Flaw Detector could meet a variety of demands with superior features, which include portable, flexible, rapid and accurate. High cost-effectiveness makes this detector the best choice for developing companies.
Features
- One Function Key, Easily Operate
- Ideal Menu Style
- Auto Calibration: Velocity, Probe Delay, Angle/K Value
Technical Specifications
| Measuring Range | 0.04 in to 472.4 in (1.0 mm to 12000 mm) |
| Resolution | 0.0004 in (0.01 mm) 0.04 in (1.00 mm) |
| Velocity | 1640.4 in/s to 65616.8 in/s (500 m/s to 20000 m/s) 20 fixed velocities settings |
| Delay | -20 µs to 3400 µs Resolution: 0.1 µs |
| Probe Delay | 0 µs to 99 µs Resolution: 0.01 µs |
| Auto Calibration | Velocity calibration & probe delay calibration |
| Linear Error | Horizontal error ≤ 0.1% Vertical error ≤ 3% |
| Dynamic Range | ≥ 36 db |
| Sensitivity | ≥ 64 db 7,87 in (200 mm) Ф2 flat-bottomed hole |
| Dimensions | 9.45 in x 7.1 in x 2.0 in (240 mm x 180 mm x 50 mm) |
| Working Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Working Humidity | 5% to 90% RH |
| Weight | 19.84 lbs (1.9kg) |
